EnVision LED
2x2, 2x4, 1x4 Edge-lite Panels
The EnVision LED Panel Series are edge-lit, available in a white frame, and designed to lay in 2x2, 2x4, or 1x4 fixtures.
9 part numbers · Edge Lit Panels- Must buy box quantities. Exceptions only made for job site dropships.
- Wattage
- 40–72W
- Lumens
- 4,600–8,280 lm
- Color temperature
- 3000K, 3500K, 4000K, 5000K
- Voltage
- 120–277V
- Dimming
- 0-10V
- CRI
- 80+
- Finish
- White
- DLC
- DLC Listed
- Warranty
- 5 years
Overview
The EnVision LED Panel Series are edge-lit, available in a white frame, and designed to lay in 2x2, 2x4, or 1x4 fixtures. Retrofit existing fluorescent troffers used in drop ceilings, enjoy minimal power consumption, long lifespan, and bright illumination. The EnVision panel are flicker-free, fully dimmable with 0-10V dimming systems, emit a shadow-less light, and are rated up to 50,000 hours.
Key features
- 1CCT
Factory options
- -EMB — 90 Minute Emergency Backup
Add the suffix to the part number when ordering. See the spec sheet for compatibility.
Part numbers & ordering
| Part # | Description | Watts | Lumens | CCT | Voltage | Dimming | Finish | DLC | Price | Add to cart | Compare | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | LED-PNL-1x4-40W-35K-LF | 1x4 LED Panel: Edge-lit-Line | 40W | 4,600 lm | 3500K | 120–277V | 0-10V | White | — | Call for pricing | ||
 | LED-PNL-1x4-40W-40K-LF | 1x4 LED Panel: Edge-lit-Line | 40W | 4,600 lm | 4000K | 120–277V | 0-10V | White | Listed | Call for pricing | ||
| LED-PNL-2x2-40W-35K-LF | 2x2 LED Panel: Edge-lit-Line | 40W | 4,600 lm | 3500K | 120–277V | 0-10V | White | Listed | Call for pricing | ||
 | LED-PNL-2x2-40W-40K-LF | 2x2 LED Panel: Edge-lit-Line | 40W | 4,600 lm | 4000K | 120–277V | 0-10V | White | — | Call for pricing | ||
| LED-PNL-2x2-40W-50K-LF | 2x2 LED Panel: Edge-lit-Line | 40W | 4,600 lm | 5000K | 120–277V | 0-10V | White | — | Call for pricing | ||
 | LED-PNL-2x4-50W-30K-LF | 2x4 LED Panel: Edge-lit-Line | 50W | 5,750 lm | 3000K | 120–277V | 0-10V | White | — | Call for pricing | ||
| LED-PNL-2x4-60W-50K-LF | 2x4 LED Panel: Edge-lit-Line | 60W | 6,900 lm | 5000K | 120–277V | 0-10V | White | — | Call for pricing | ||
| LED-PNL-2x4-72W-40K-LF | 2x4 LED Panel: Edge-lit-Line | 72W | 8,280 lm | 4000K | 120–277V | 0-10V | White | — | Call for pricing | ||
| LED-PNL-2x4-72W-50K-LF | 2x4 LED Panel: Edge-lit-Line | 72W | 8,280 lm | 5000K | 120–277V | 0-10V | White | — | Call for pricing |
