EnVision LED
Square Canopy Fixtures 3CCT + 3-Power Selectable w/ Twist-C Technology (View compatible sensors on spec sheet) + 10% Up-Light Optics
Light up your outdoor area with the EnVision Bolt Series, a line of Area Light fixtures with high lumen per watt efficacy (minimum 145lm/w).
4 part numbers · Canopy LED Fixtures
- Wattage
- 30–90W
- Lumens
- 4,200–13,050 lm
- Color temperature
- 3000K, 4000K, 5000K
- Voltage
- 120–277V
- Dimming
- 0-10V
- CRI
- 80+
- Finish
- Bronze, White
- DLC
- DLC Premium
- Warranty
- 5 years
Overview
Light up your outdoor area with the EnVision Bolt Series, a line of Area Light fixtures with high lumen per watt efficacy (minimum 145lm/w). The Bolt Wall Packs are available in a variety of different styles: non-cutoff, fully cut-off, semi cut-off, adjustable, and a rotatable up/down light. EnVision's rotating wall pack is an architectural LED luminaire that allows end users to rotate the modules in a complete 360º to light up a desired area. The fixtures are slim and low profile while providing a high lumen output.
Key features
- 3CCT
- Select-N-Switch
Part numbers & ordering
| Part # | Description | Watts | Lumens | CCT | Voltage | Dimming | Finish | DLC | Price | Add to cart | Compare | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | LED-SQUC-3P60-TRI-BZ | Square Canopy: ARCY-Line | 30/45/60W | 4,200/6,300/8,400 lm | 3000K/4000K/5000K | 120–277V | 0-10V | Bronze | Premium | Call for pricing | ||
 | LED-SQUC-3P60-TRI-WH | Square Canopy: ARCY-Line | 30/45/60W | 4,200/6,300/8,400 lm | 3000K/4000K/5000K | 120–277V | 0-10V | White | Premium | Call for pricing | ||
| LED-SQUC-3P90-TRI-BZ | Square Canopy: ARCY-Line | 70/80/90W | 10,150/11,600/13,050 lm | 3000K/4000K/5000K | 120–277V | 0-10V | Bronze | Premium | Call for pricing | ||
| LED-SQUC-3P90-TRI-WH | Square Canopy: ARCY-Line | 70/80/90W | 10,150/11,600/13,050 lm | 3000K/4000K/5000K | 120–277V | 0-10V | White | Premium | Call for pricing |
