EnVision LED
Trimless Surface Mounts
• Stocked in 30K: other CCT available with lead time • Di-cast aluminum housing for better heat dissipation • Available in white, black, brushed nickel finish • Closet Rated according to NEC Section 410.6 & 410.8 • Optional Emergency Backup
16 part numbers · Trimless Surface Mounts
- Wattage
- 12–20W
- Lumens
- 850–1,500 lm
- Color temperature
- 2700K, 3000K, 3500K, 4000K, 5000K
- Voltage
- 120V
- Dimming
- TRIAC/ELV
- CRI
- 90+
- Finish
- White
- Warranty
- 5 years
Overview
• Stocked in 30K: other CCT available with lead time • Di-cast aluminum housing for better heat dissipation • Available in white, black, brushed nickel finish • Closet Rated according to NEC Section 410.6 & 410.8 • Optional Emergency Backup Available: delivers full lumens in EM mode • L70 @ 50,000 Hours lumen maintenance
Key features
- 5CCT
- 1CCT
Part numbers & ordering
| Part # | Description | Watts | Lumens | CCT | Voltage | Dimming | Finish | DLC | Price | Add to cart | Compare | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | LED-TSM-5R-12W-30K-BLK | 5" Round Surface Mount: Trimless-Line | 12W | 850 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
 | LED-TSM-5R-12W-30K-BN | 5" Round Surface Mount: Trimless-Line | 12W | 850 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-5R-12W-5CCT-WH | 5" Round Surface Mount: Trimless-Line | 12W | 850 lm | 2700K/3000K/3500K/4000K/5000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
 | LED-TSM-7R-15W-30K-BLK | 7" Round Surface Mount: Trimless-Line | 15W | 1,100 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-7R-15W-30K-BN | 7" Round Surface Mount: Trimless-Line | 15W | 1,100 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
 | LED-TSM-7R-15W-5CCT-WH | 7" Round Surface Mount: Trimless-Line | 15W | 1,100 lm | 2700K/3000K/3500K/4000K/5000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-9R-18W-30K-BLK | 9" Round Surface Mount: Trimless-Line | 18W | 1,300 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-9R-18W-30K-BN | 9" Round Surface Mount: Trimless-Line | 18W | 1,300 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-9R-18W-30K-WH | 9" Round Surface Mount: Trimless-Line | 18W | 1,300 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-9R-18W-5CCT-WH | 9" Round Surface Mount: Trimless-Line | 18W | 1,300 lm | 2700K/3000K/3500K/4000K/5000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-11R-20W-30K-BLK | 11" Round Surface Mount: Trimless-Line | 20W | 1,500 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-11R-20W-30K-BN | 11" Round Surface Mount: Trimless-Line | 20W | 1,500 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
 | LED-TSM-11R-20W-30K-WH | 11" Round Surface Mount: Trimless-Line | 20W | 1,500 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
 | LED-TSM-11R-20W-5CCT-WH | 11" Round Surface Mount: Trimless-Line | 20W | 1,500 lm | 2700K/3000K/3500K/4000K/5000K | 120V | TRIAC/ELV | White | — | Call for pricing | ||
| LED-TSM-5R-12W-30K-WHDISC | 5" Round Surface Mount: Trimless-Line | 12W | 850 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | — | |
| LED-TSM-7R-15W-30K-WHDISC | 7" Round Surface Mount: Trimless-Line | 15W | 1,100 lm | 3000K | 120V | TRIAC/ELV | White | — | Call for pricing | — |
