Keystone Technologies
Surface Mount – Panel Surface
Surface mount panels with combination dimming (0-10V, TRIAC, reverse phase) to work with a variety of systems.
3 part numbers · Downlights
- Wattage
- 17–44W
- Lumens
- 1,500–4,000 lm
- Color temperature
- 2700K, 3000K, 3500K, 4000K, 5000K
- Voltage
- 120–277V
- Dimming
- Combination
- CRI
- 90+
- Finish
- White
- Warranty
- 5 years
Overview
Surface mount panels with combination dimming (0-10V, TRIAC, reverse phase) to work with a variety of systems. Available in multiple sizes, they feature a slide-lock mounting plate and install easily in numerous spaces. With both Power and Color Select.
Part numbers & ordering
| Part # | Description | Watts | Lumens | CCT | Voltage | Dimming | Finish | DLC | Price | Add to cart | Compare | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | KT-SMLED22PS-12D-9CSF-CDIM | 1x2 LED Surface Mount Panel | Power Select 22/17W | Color Select 2700/3000/3500/4000/5000K | 120-277V Input | 90 CRI | Tri-mode dimming | 17/22W | 1,500/2,000 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | Combination | White | — | Call for pricing | ||
 | KT-SMLED44PS-14D-9CSF-CDIM | 1x4 LED Surface Mount Panel | Power Select 44/33W | Color Select 2700/3000/3500/4000/5000K | 120-277V Input | 90 CRI | Tri-mode dimming | 33/44W | 3,000/4,000 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | Combination | White | — | Call for pricing | ||
 | KT-SMLED44PS-22D-9CSF-CDIM | 2x2 LED Surface Mount Panel | Power Select 44/33W | Color Select 2700/3000/3500/4000/5000K | 120-277V Input | 90 CRI | Tri-mode dimming | 33/44W | 3,000/4,000 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | Combination | White | — | Call for pricing |
