ABB Pool Circuit Breakers

Overview

The ABB TL412R260GF spa panel features space for 4, 1 inch breakers and a 60 A bus ampere rating. It includes a factory-installed 60A GFCI breaker, providing protection for spas, hot tubs, and pools. Constructed with a weather-resistant NEMA 3R rated steel enclosure for outdoor environments. Key Features 60A 2-pole 240V GFCI Breaker included Unit has 2 additional 1 inch spaces for extra circuits Outdoor suitable enclosure Technical Specifications Category : Load Centers Grouping : Single Phase - USA 1 inch Space : 4 Circuit Breaker Style : Plug-In Device type : Main Lug Door : Yes Enclosure : Outdoor Enclosure Type : NEMA 3R Factory Installed Ground Kit : Yes Feed : Either Load Center Type : Pool and Spa NEMA Rating : NEMA 3R Phase : 1 Phase Wires : 3 Wire UL/CUL Listing : UL Voltage Rating : 240 V Amperage Rating : 60 Amp Standard : UL Listed Wiring Configuration : 3 Wire Number of Phases : 1 Maximum Current : 60 Amps Number Of Circuits : 8 Phase Type : Single Phase Material Type : Alloy Steel, Copper, Plastic Standard Information Brand : ABB Manufacturer Part Number : TL412R260GF
