2x2 LED Panel feat. Power Select & Color Select with Embedded Smartloop PIR Sensor. 40/30/20W, 120-277V Input, 3500/4000/5000K, 0-10V Dimming, Backlit Design.

Name: 2x2 LED Panel feat. Power Select & Color Select with Embedded Smartloop PIR Sensor. 40/30/20W, 120-277V Input, 3500/4000/5000K, 0-10V Dimming, Backlit Design. (KT-BPLED40PS-22B-8CSA-VDIM /FC2)
Brand: Keystone Technologies
SKU: KT-BPLED40PS-22B-8CSA-VDIM /FC2

KT-BPLED40PS-22B-8CSA-VDIM /FC2

Final production — limited stock

20/30/40W · 2,500/3,500/4,500 lm · 3500K/4000K/5000K · 120–277V

Part of Panels & Troffers – Back-lit Flat Panel

Call for pricing Add it to your cart and send us a quote request — or call 678-467-5515.

Request a Quote Spec sheetCompare

Distributor pricing and stock: call 678-467-5515 or email sales@discountkings.net.

Specifications

Electrical
Wattage	20/30/40W (selectable)
Voltage	120–277V
Dimming	0-10V

Photometric
Lumens	2,500/3,500/4,500 lm
Efficacy	112.5 lm/W
Color temperature	3500K/4000K/5000K (selectable)
CRI	80+

Physical
Mounting	Ceiling Mount
Size	2x2
Finish	White

Ratings & certifications
DLC	DLC Listed

Lifetime, warranty & ordering
Rated life	50,000 hrs
Warranty	5 years
UPC	843654151595
Pack quantity	2

2x2 LED Panel feat. Power Select & Color Select with Embedded Smartloop PIR Sensor. 40/30/20W, 120-277V Input, 3500/4000/5000K, 0-10V Dimming, Backlit Design.
