1 / 18
EnVision LED
2' X-Shape Downlight
6 part numbers · Indoor Lighting
- Wattage
- 20–50W
- Lumens
- 2,400–6,000 lm
- Color temperature
- 2700K, 3000K, 3500K, 4000K, 5000K
- Voltage
- 120–277V
- Dimming
- 0-10V
- CRI
- 80+
- Finish
- Black, White
- Warranty
- 5 years
Key features
- 5CCT
- Select-N-Switch
Part numbers & ordering
| Part # | Description | Watts | Lumens | CCT | Voltage | Dimming | Finish | DLC | Price | Add to cart | Compare | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | LED-ALIN2-FL-22X22-X-3P50-D-5CCT-BL | 2' X-Shape Downlight | 20/30/40W | 2,400/3,600/4,800 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | 0-10V | Black | — | Call for pricing | ||
 | LED-ALIN2-FL-22X22-X-3P50-D-5CCT-WH | 2' X-Shape Downlight | 20/30/40W | 2,400/3,600/4,800 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | 0-10V | White | — | Call for pricing | ||
 | LED-ALIN2-FL-22X22-X-3P50-UD-5CCT-BL | 2' X-Shape Downlight | 25/38/50W | 3,000/4,560/6,000 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | 0-10V | Black | — | Call for pricing | ||
 | LED-ALIN2-FL-22X22-X-3P50-UD-5CCT-WH | 2' X-Shape Downlight | 25/38/50W | 3,000/4,560/6,000 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | 0-10V | White | — | Call for pricing | ||
 | LED-ALIN2-FL-22X22-X-3P50-UDID-5CCT-BL | 2' X-Shape Downlight | 25/38/50W | 3,000/4,560/6,000 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | 0-10V | Black | — | Call for pricing | ||
 | LED-ALIN2-FL-22X22-X-3P50-UDID-5CCT-WH | 2' X-Shape Downlight | 25/38/50W | 3,000/4,560/6,000 lm | 2700K/3000K/3500K/4000K/5000K | 120–277V | 0-10V | White | — | Call for pricing |
Downloads
- Spec sheetPDF
- Installation guidePDF
- IES fileled-alin2-22x22-x-3p50-d-5cct-wh-50w.ies
- IES fileled-alin2-22x22-x-3p50-d-5cct-wh-38w.ies
- IES fileled-alin2-22x22-x-3p50-d-5cct-wh-25w.ies
- IES fileled-alin2-22x22-x-3p50-d-5cct-wh-50w.ies
- IES fileled-alin2-22x22-x-3p50-d-5cct-wh-25w.ies
- IES fileled-alin2-22x22-x-3p50-d-5cct-wh-38w.ies
